Parameter:
Capacity:20-150 ton
Stroke:50-250 mm
Maximum Operating Pressure:700 bar
Product Features:
•Hollow plunger allows for both pull and push forces
•High strength spring return for rapid retraction
•Composite bearings prevent metal-to-metal contact,
increasing cylinder life and resistance to side-loads of up to 10%
•Floating center tube increases seal and product life
•Handles included on all models
•Intergal stop ring prevents plunger over-travel and iscapable of withstanding the full cylinder capacity
•Hard-Coat finish on all surfaces resists damage and enable longer cylinder life
•Internal thread on the plunger for connection purpose
